Switch PoE 19 cổng Scodeno S200-19GTP-SG2-ACR-VT

Liên hệ

Nguồn vào: AC 100~240V/50-60HZ

Nhiệt độ hoạt động: -10℃ ~ +50℃

Switch Chipset: RTL,

PSE chipset: RTL, Support PoE Negotiation

Vỏ máy: Kim loại, Làm mát tự nhiên

Chứng chỉ: CE/FCC/RoHS

ESD: 8KV-15KV

MTBF: 100000 Giờ

Cổng RJ45:

  • 16 cổng RJ45 hỗ trợ chuẩn 10/100Base-T
  • 1 cổng RJ45 hỗ trợ chuẩn 10/100/1000 Base-T

Cổng Combo:

  • 1 cổng Combo (có thể sử dụng cáp RJ45 hoặc cáp quang SFP)

Tiêu chuẩn PoE: IEEE802.3af/at

Tổng công suất PoE: ≤ 300W  thiết bị PoE.

Tốc độ chuyển tiếp: 6.84Mpps

Dung lượng chuyển mạch: 9.2Gbps



Mô tả

Switch Interface
Lan Ports 16*10/100Mbps RJ45 Ports
Power interfaceAC220V
LED IndicatorsPWR
Wan (Uplink Ports )2×10/100/1000Mbps RJ45 + 1*1000Mbps SFP
Network Topology
Ring topology)   No Managed
Star topology)Managed
Bus topology)Managed
Tree Topology)Managed
Electrical Specifications
Input voltageAC 100-240V 50/60Hz
Total Power consumption≤300W
Main board power)  <10W



PoE Features
PoE Standard 802.3AF,802.3AT,
PoE Pin 1,2+/3,6-
PoE Ports 1-16, 1-16 Ports single port max support 30W
AI DIP Switches
1Ai PoE
21-8 Ports support 250m power and data transmission
31-16 Port are self isolated from each other
41-16 Ports self control the network storm within 3%
Switch Performance
Switching capacity                        9.2G
Packet forwarding rate                    6.84Mpps
MAC address table                2K
Buffer                  1M
Forwarding delay                         <5us
MDI/MDIX                      Support
Jumbo FrameSupport 2K bytes
Storm ControlSupport
Working Environment
Operating temperature)                    -10℃~+50℃
Storage temperature)                  -40℃~+70℃
Relative humidity)                          5%~95% non-condensing
Thermal methods)                          Fan less Design,
MTBF                                                   100,000 Hours
Mechanical Dimensions
Product size                                    319*208*45mm
Installation                          Desk top
Net Weight                                         1.66kg
EMC&INGRESS PROTECTION
Surge protection of Power      General 6KV,Difference 2KV
Surge protection of Ethernet port      General 6KV,Difference 2KV
ESD Contact :8K, Air :15K
Free fall                                   0.5m
Accessories
AccessoriesSwitch Devices,  Power cable,  Manual
