Key Features:
Optics
-
Day/Night functionality
-
Smart IR with a range of up to 30m (98ft)
-
Wide Dynamic Range (WDR) technology up to 120 dB
-
2D/3D Digital Noise Reduction (2D/3D DNR)
Compression
-
Supports Ultra 265, H.264, MJPEG
-
Built-in smart algorithm
-
ROI (Region of Interest) function
-
Customized OSD (On-Screen Display)
Network
-
Compatible with ONVIF standard
Structure
-
Wide operating temperature range: -35°C ~ 60°C (-31°F ~ 140°F)
-
Supports ±25% wide voltage input range
-
Vandal resistance rating: IK10
-
Dust and water resistance: IP67
-
3-Axis rotation design
Experience superior image quality, higher resolution, and a more convenient cabling system today!
Device Specifications:
| Feature | Description |
| Image Sensor | 1/3″, 4.0 megapixel, progressive scan, CMOS |
| Image Size | 2592×1520 |
| Resolution | 4.0 megapixel |
| IR Range | Up to 30m (98ft) |
| Dimensions | Φ108.5 × 81mm (Ø4.28” × 3.2”) |
| Power Supply | DC 12V±25%, PoE (IEEE 802.3af) |
| Minimum Illumination | Color: 0.03Lux (F2.0, AGC ON); 0Lux with IR on |
| Video Compression | Ultra 265, H.264, MJPEG |
| Video Resolution | Main stream: 4MP (2592 × 1520), up to 20fps |
| Network Interface | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
| Integration & Compatibility | ONVIF (Profile S, Profile G, Profile T), API |
| Operating Environment | -35°C ~ 60°C (-31°F ~ 140°F), Humidity ≤95% RH (non-condensing) |
